c30. WTEC II TRANSMISSION ECU PUSHBUTTON SHIFT SELECTOR (TEPSS) DISPLAYS MAIN
CODE 41, 42, 44, AND/OR 45 SUB CODE 22 (PRIOR TO SERIAL NUMBER 6510032369
WITH TRANSMISSION ADAPTER CABLE ASSEMBLY) (CONT)
KNOWN INFO
TEST OPTIONS
REASON FOR QUESTION
CAUTION
Read CAUTION
on following page.
NO
YES
7.
POSSIBLE PROBLEMS
Resistance Test or
STE/ICE-R Test #91
Replace WTEC II TEPSS
(TM 9-2320-365-20-3).
Replace G solenoid
(para 7-11).
Circuit breaker OK.
Batteries OK.
WTEC II cab transmission
harness OK.
Transmission external wiring
harness OK.
Transmission adapter cable
assembly OK.
Transmission internal wiring
harness OK.
Faulty G solenoid.
Faulty WTEC II TEPSS.
Is 2.5-5.0 ohms resistance
present from G solenoid
pin A to pin B?
If 2.5-5.0 ohms is not present,
G solenoid is faulty. If 2.5-5.0
ohms is present, WTEC II
TEPSS is faulty.
